05X Series Vibrating Screen

Product Introduction

OREPEAK 05X series vibrating screen features high vibration intensity. Under the same specifications, it offers greater processing capacity and higher screening efficiency compared to traditional equipment. Especially suitable for heavy, medium, and fine screening operations, widely used for primary crushing, secondary crushing and finished product screening.

Feed size: 0-300mm, Processing capacity: 45-2250 tons/hour, Applicable materials: Granite, marble, basalt, limestone, quartz, river pebbles, copper ore, iron ore, etc.

Working Principle

The O5X vibrating screen is equipment that uses rubber springs as elastic support elements and OV ultra-energy exciters as vibration sources. The eccentric block rotation generates exciting force, causing the screen box to produce circular reciprocal motion. Materials continuously perform approximate circular bouncing and rolling movements on the inclined screen surface. Through repeated comparison with screen openings, materials smaller than the openings pass through the screen, while larger materials remain on the screen surface, thus completing the screening process.

Product Advantages

High vibration intensity, large processing capacity: The 05X series vibrating screen features high vibration intensity. Under the same specifications, it offers greater processing capacity and higher screening efficiency compared to traditional equipment.
Wide application range: Especially suitable for heavy, medium, and fine screening operations, widely used for primary crushing, secondary crushing and finished product screening.
Stable structure, reliable operation: Using rubber springs as support elements, the equipment operates smoothly and reliably with low noise.
Easy maintenance: Modular design with high parts commonality, convenient and quick maintenance and replacement.

Technical Parameters

Model	Screen Size(mm)	Layers	Screen Angle(°)	Screen Hole Size(mm)	Max Feed Size(mm)	Vibration Frequency(r/min)	Double Amplitude(mm)	Processing Capacity(t/h)	Power(kW)	Overall Dimensions(mm)
O5X1545-2	1500×4500	2	18(18-25)	2-70	200	800-900	7-12	45-380	15	4796×3190×2829
O5X1545-3	1500×4500	3	18(18-25)	2-70	200	800-900	7-12	45-380	15	4796×3190×3407
O5X1845-2	1800×4500	2	18(18-25)	2-70	200	800-900	7-12	60-450	15	4797×3490×2853
O5X1845-3	1800×4500	3	18(18-25)	2-70	200	800-900	7-12	60-450	22	4797×3623×3431
O5X1860-2	1800×6000	2	18(18-25)	2-70	200	800-900	7-10	75-600	15	6223×3607×3437
O5X1860-3	1800×6000	3	18(18-25)	2-70	200	800-900	7-12	75-600	30	6223×3648×4016
O5X1860-4	1800×6000	4	18(18-25)	2-70	200	800-900	7-12	75-600	37	6223×3670×4436
O5X2160-2	2100×6000	2	18(18-25)	2-70	200	800-900	7-12	85-700	22	6223×3907×3437
O5X2160-3	2100×6000	3	18(18-25)	2-70	200	800-900	7-12	85-700	30	6223×3948×4016
O5X2160-4	2100×6000	4	18(18-25)	2-70	200	800-900	7-11	85-700	37	6223×3970×4436
O5X2460-2	2400×6000	2	18(18-25)	2-70	200	800-900	7-12	100-800	22	6223×4207×3437
O5X2460-3	2400×6000	3	18(18-25)	2-70	200	800-900	7-11	100-800	30	6223×4248×4016
O5X2460-4	2400×6000	4	18(18-25)	2-70	200	800-900	7-10	100-800	37	6223×4270×4436
O5X2760-2	2700×6000	2	18(18-25)	2-70	200	800-900	7-12	120-900	30	6223×4550×3469
O5X2760-3	2700×6000	3	18(18-25)	2-70	200	800-900	7-11	120-900	37	6223×4570×4038
O5X3072-2	3000×7200	2	20(20-25)	2-70	200	800-900	7-11	150-1200	37	7277×4820×4238

Note: Product images, models, data, functions, performance, specifications and parameters on this website are for reference only and may be subject to improvement. For specific information, please refer to the actual product and product manual. Unless otherwise specified, the interpretation rights of all data on this website belong to the company.
