PE Series Impact Crusher

Product Introduction

PF series impact crusher uses impact energy to crush materials, has large crushing ratio, and the crushed materials are cubic particles. Widely used in building materials, ore crushing, railways, highways, energy, water conservancy, mining, chemical and other industries for medium and fine crushing. The discharge particle size can be adjusted and crushing specifications are diverse.

Feed size: 0-350mm, Production capacity: 50-260 tons/hour, Applicable materials: limestone, feldspar, calcite, talc, barite, dolomite, white clay, kaolin, gypsum, graphite, etc.

Working Principle

PF series product uses impact energy to crush materials. During operation, the rotor rotates at high speed driven by the motor. Materials entering through the feed inlet collide with the plate hammer on the rotor and are crushed by the high-speed impact of the plate hammer. The crushed materials are then thrown back to the lining plate for secondary crushing. Finally, they are discharged from the discharge outlet. Adjusting the gap between the impact frame and rotor frame can change the discharge size and material shape.

Product Advantages

High Wear Resistance Plate Hammer, Long Service Life: The plate hammer is made of high-chromium material combined with wear-resistant material through a special casting process and strict heat treatment, having good resistance to mechanical and thermal impacts.
Semi-automatic Safety Design, Effectively Reducing Overload Risk and Maintenance Downtime: PF impact crusher is equipped with a gravity safety device on the rear frame. When non-crushable materials (such as iron blocks) enter the crushing cavity, the equipment can automatically discharge and reset, avoiding equipment overload risks and downtime losses from maintenance.
Mechanical Adjustment Device Design, Easy Discharge Size Adjustment: PF impact crusher is equipped with a mechanical adjustment device at the top. For different needs at different stages, users can adjust the gap between the impact frame and rotor by turning the device bolt to achieve discharge size adjustment.
Using Ratchet Cover Device, Easier Parts Replacement and Maintenance: PF impact crusher is equipped with identical ratchet cover devices on both sides of the frame. This device consists of high-strength left and right rotating trapezoidal screws and ratchet reversing mechanism. When the impact crusher needs to be stopped for parts replacement and maintenance, users can easily and smoothly open and close the rear top cover for maintenance operations.

Technical Parameters

Model	Rotor Specification(mm)	Feed Opening Size(mm)	Max Feed Size(mm)	Capacity(t/h)	Power(kW)	Overall Dimensions(mm)
PF1010	Φ1000×1050	400×1080	350	50-80	75	2455×2086×2800
PF1210	Φ1250×1050	400×1080	350	60-120	110	2590×2050×2810
PF1214	Φ1250×1400	400×1430	350	80-160	132	2590×2400×2810
PF1315	Φ1300×1500	860×1520	350	120-260	200	2930×2760×3050

Note: Product images, models, data, functions, performance, specifications and parameters on this website are for reference only and may be subject to improvement. Please refer to the actual product and instruction manual for specific information. Unless otherwise specified, the right to interpret all data on this website belongs to the company.
